Pedrollo HF High Flow Centrifugal Pump

Product Information

Pedrollo HF High Flow Centrifugal Pump

2 Year Manufacturers Warranty

A top quality, Italian made, High Flow Centrifugal pump, for use with any fluids that are not chemically agressive to its component materials

Wetted Components
Pump Body	Cast Iron (Painted)
Impellor Case	Cast Iron (Painted)
Impellor Case Seal	NBR
Motor Shaft Seal	NBR
Vanes	Not Present
Vane Springs	Not Present
Rotor / Gear / Impellor	Brass
Shaft Key / Nut	304 Stainless Steel
Motor Shaft	304 Stainless Steel
Bypass Valve Piston	Not Present
Bypass Valve Seal	Not Present
Bypass Valve Spring	Not Present

Performance
Voltage / Frequency	110v50Hz, 230v50Hz, or 415v50Hz
kW	Various, Consult PDF Below
Amps	Various, Consult PDF Below
RPM	2900
Duty Cycle	Continuous
Cable Length	Not Present
Bypass Valve Y/N	N
Max Flow	Various, Consult PDF Below
Discharge Pressure	Various, Consult PDF Below
Max Suction Lift (Dry)	None
Max Suction Lift (Wet)	7 m
Inlet Fitting	Various, Consult PDF Below
Outlet Fitting	Various, Consult PDF Below
Max Particle Tolerance	100 Micron
Max Liquid Temp	+90 Celcius
Min Liquid Temp	-10 Celcius
Max Room Temp	+40 Celcius
Min Room Temp	TBC
Thermal Protection Y/N	Y
Max Liquid Viscosity	Water
Ingress Protection	IP44

Options Available
Single Phase 230v	Three Phase 415v	kW (230v)	lpm	Head (m)
HFm 50B	HF 50B	0.37	100-300	8-3
HFm 50A	HF 50A	0.55	100-300	11-6
HFm 51B	HF 51B	0.60	100-300	16-5
HFm 51A	HF 51A	0.75	100-300	19-8
HFm 60	HF 60	1.10	100-300	26.5-15
HFm 70B	HF 70B	1.50	100-300	30.5-19
	HF 70A	2.20	100-300	36.5-25
HFm 4	HF 4	0.75	100-800	10-3
HFm 5C	HF 5C	0.60	100-400	12-7
HFm 5B	HF 5B	0.75	100-500	13-5
HFm 5A	HF 5A	1.10	100-600	14-3
HFm 5BM	HF 5BM	1.10	100-500	19-7
HFm 5AM	HF 5AM	1.50	100-500	22-10
HFm 6C	HF 6C	1.10	200-1000	12-3
HFm 6B	HF 6B	1.50	200-1100	15-5
	HF 6A	2.20	200-1200	18-6
	HF 8B	3.00	200-1200	21-9
	HF 8A	4.00	200-1200	24-13
	HF 20B	3.00	400-1700	15.5-2
	HF 20A	4.00	400-1800	18.5-2
	HF 30B (Cast Iron Impellor)	5.50	600-2000	18-12
	HF 30A (Cast Iron Impellor)	7.50	600-2200	23-18

For 110v 50Hz, and 60Hz motors please email us for availability and price. As a rule, where available, 110v motors or 60Hz options are 15% more exensive than their 230v counterparts

Download Pedrollo HF50A Pump, 300 lpm PDF

Product Options:

(All prices include VAT)

HF 20A - (£1270.00)
HF 20B - (£1121.00)
HF 30A - (£1586.00)
HF 30B - (£1496.00)
HF 4 - (£461.00)
HF 50A - (£324.00)
HF 50B - (£311.00)
HF 51A - (£395.00)
HF 51B - (£384.00)
HF 5A - (£454.00)
HF 5AM - (£653.00)
HF 5B - (£432.00)
HF 5BM - (£600.00)
HF 5C - (£427.00)
HF 60 - (£623.00)
HF 6A - (£813.00)
HF 6B - (£793.00)
HF 6C - (£758.00)
HF 70A - (£641.00)
HF 70B - (£621.00)
HF 8A - (£1268.00)
HF 8B - (£1121.00)
HFm 4 - (£450.00)
HFm 50A - (£309.00)
HFm 50B - (£302.00)
HFm 51A - (£395.00)
HFm 51B - (£364.00)
HFm 5A - (£454.00)
HFm 5AM - (£653.00)
HFm 5B - (£409.00)
HFm 5BM - (£600.00)
HFm 5C - (£406.00)
HFm 60 - (£623.00)
HFm 6B - (£786.00)
HFm 6C - (£758.00)
HFm 70B - (£621.00)
