Swing Check Valve, Forged Steel, 800LB Socket Weld
- Socket Weld
- Body ASTM A105 Forged Carbon Steel
- Bonnet ASTM A105 Forged Carbon Steel
- Disc ASTM A182 Forged Stainless Steel
- Seat ASTM A182 Forged Stainless Steel
- Gasket Spiral Wound Stainless Steel & Graphite
- Bolted Cover, Bolts A193 B7 Steel
- Trim & Hinge 13%Cr
- Washer A29 1035 Carbon Steel
- Nut A194 2H Carbon Steel
- Yoke ASTM A105 Forged Carbon Steel
- Design to API 602
- Tested to API 598
- Rated ASME CL800, MAx Pressure 136.2 Bar @ -29 to +38 c
- Temperature -29ºC to 538ºC
- For use with any fluids which are not agressive to the valves component materials
For full specifications download PDF datasheet below.
Download Swing Check Valve, Forged Steel, 800LB BSP - Datasheet PDF
