Toyota Hilux Mk6 Front & Rear Diff Breather Extension System
  • Click to enlarge

Toyota Hilux, Mk6 Front & Rear Diff Breather Extension System

Designed for the Mk6 KUN25 / KUN26 Hilux, but suitable for any other models of Toyota Hilux, with 1/8"BSP female threaded rear diff breather valve port, and 1x 8mmID + 1x3-5mmID front diff breather hoses.

Kit includes:

  • 2x 1/8"BSPM-8mm Hydraulic Stud (Nickle Plated Brass with Oring face seal)
  • 8m of 8mmOD Yellow Nylon Hydraulic Tubing
  • 1x 1/8"BSPF Brass/Bronze Silencer
  • 3x 8mm Plastic Hydraulic Tees
  • 3x 8mm Hose Jubilee Clip
  • 2x 5mm-8mm Hose Connector
  • 3X 5cm lengths of 8mmID Hose

The Sintered Bronze Silencer keeps out dirt better than the original valves, and allows unrestricted air-flow into the diff when rapid cooling creates a vacuum, this prevents the differentials from sucking in water through the drive shaft seals - this bronze silencer must be fitted above the water line or through the side of your air box. As standard the Toyota diff breather valves would prevent water from entering the diff through itself once it is submerged, but it will not prevent drawing of water through the drive shaft seals, also, if the breather valve fails, and allows water in, the first thing you will know is that your diff seizes up, this is avoided by allowing fast air flow into the diff from a point above the water.

The self cleaning nylon tube push-fits into the hydraulic stud through a rubber o'ring and is gripped in place automatically, creating an air and watertight seal. The nylon tube is crush and split resistant, and it will reform itself should it become crushed.

We offer two colour options - yellow tube which is highly visible, so that it can be visually checked from distance to ensure nothing is left, or becomes, disconnected, or a black version is also available in options below if this is preferred.

Other  equipment in the engine bay can also be connected into this water tight system by purchasing extra tees and tube. For example, Spot Lights.

Shown Below, these are the original breathers that are replaced by using this kit, the screwed breather is the rear diff breather and has a valve in it, the two breathers with hose tails are the front diff breathers and these are not valved at all, water can enter these readily. The main image listing shows the two hoses which these were attached to, being connected into the nylon tubing, the narrower hose utilises the blue connector and clear sleeve to connect it to the yellow nylon. there is also a breahter connection for the gearbox.

Download Oilybits Diff Breather Kit PDFDownload Oilybits Diff Breather Kit PDF

Product Options

£30.95
